Ecogreen EG-D Garment Dyeing Machines
Models: EG-D 05 – EG-D 25 – EG-D 60 – EG-D 130 – EG-D 220 – EG-D 400 – EG-D 500
50 years of experience in garment dyeing in Yılteks guided us to create the HBM-D series Garment Dyeing Machines. By 2021 this legendray dyeing machine is evolving to a state of the art technology by with the help of Yilmak’s patented pumpless water circulation system. Patented Water Circulation System of ECOGREEN-D Garment Dyeing Machines saves an important amount of water and chemicals. ECOGREEN-D Dyeing Machines provide perfect solutions for reactive dyeing, pigment dyeing, dischargeable dyeing, direct dyeing, and all other garment dyeing operations.
Technical Specifications
| Model | DRUM VOLUME (lt) | DRUM DIAMETER (mm) | DRUM DEPTH (mm) | VARIABLE SPEED (rpm) | INSTALLED POWER (kW) | HEIGHT x WIDTH x DEPTH (mm) |
|---|---|---|---|---|---|---|
| EG-D 05 | 50 | 530 | 225 | 0-100 | 0,25 | 1400X670X570 |
| EG-D 25 | 260 | 817 | 500 | 0-100 | 1,1 | 1450X1250X1020 |
| EG-D 60 | 585 | 1010 | 730 | 0-100 | 3 | 1800X1520X1325 |
| EG-D 130 | 1300 | 1355 | 900 | 0-100 | 5,5 | 2250X2150X1700 |
| EG-D 220 | 2105 | 1495 | 1200 | 0-100 | 10 | 2350X2100X2200 |
| EG-D 400 | 3875 | 1845 | 1450 | 0-100 | 18 | 2780X2450X2650 |
| EG-D 500 | 5160 | 1845 | 1930 | 0-100 | 21 | 2850X2450X3300 |
